AHSUB15S
15" AH Series Stadium Subwoofer Systems
The AHSUB15S subwoofer system features high output and amazing low frequency response for indoor and outdoor applications including football stadiums, sports arenas, baseball fields, and large auditoriums.
Unit features an efficient low frequency woofer loaded into a durable, weather resistant, rear firing enclosure.
Tech Data
Specifications
250 Watts power handling
Easy installation. Secure surface mounting or suspension installation is possible via the integral forged eyebolts.
Easy, weather resistant connection via a convenient recessed terminal block located on the back of the loudspeaker
Impressive efficiency rating of 103dB 1Watt/1Meter makes the AHSUB15S a perfect choice for low frequency augmentation of high energy music playback at sporting events.
Maximum output of 127dB (Rated Power @ 1M)
Weather & rodent resistant. Rear firing woofer cavity and mesh screen over the enclosure front protects the speaker from weather and/or rodent damage.
Height
30 9/16" (77.6224 cm)
Width
30" (76.2 cm)
Depth
29 1/8" (73.914 cm)
Shipping Weight
181.00 lbs (82.10 kgs)
Frequency Response
55Hz to 120Hz (±5dB)
Driver Type
15" Low Freq Cone
Dispersion
Omni
Power Rating
250 Watts
Sensitivity
103dB SPL (1W/1M)
Installation Sheets
Data Sheet
CAD Drawing
Brochure
