VP14MB
14 Gauge Steel Vandal Resistant 4W (70.7V/25V) Speaker Motorboard - "Beige" Finish
Designed specifically for installations that may be targeted by vandals, the VP14 system from Atlas Sound provides highly intelligible speech reinforcement with the added benefit of extreme ruggedness. To address division of labor requirements VP components are ordered separately.
The VP14MB vandal resistant slanted wall mount baffle, finished in attractive, neutral beige, is ideal for use in high-security areas such as schools and correctional facilities. It's sturdy, 14-gauge baffle construction and specially designed protective labyrinth screen protects the enclosed speaker assembly against abuse. Each package contains a high-quality 8" diameter loudspeaker with a 10-ounce ceramic magnet and pre-assembled 25V/70.7V transformer with five power taps terminated to a euro block style connector. This connector includes 3 empty blocks to allow through connection of other devices such as call switches or intercom phones without the need for wire nuts.
Tech Data
Specifications
9.5° Sloped Design Offers Directional Sound Projection
Attractive Design is Suitable for Use in a Variety of Surface-Mount Vandal Proof Applications
Beige Finish
Durable All-steel Construction
Impermeable Security Grille Protects Speaker
Includes High-Quality 8" Loudspeaker with 25V/70.7V Line Transformer
Height
110 7/16" (29.05125 cm)
Width
11 3/4" (29.845 cm)
Depth
3 1/4" (8.255 cm)
Shipping Weight
6.20 lbs (2.81 kgs)
Frequency Response
50Hz - 15kHz
Power Taps
.25, .5, 1, 2, & 4
Dispersion
105º
Sensitivity
96dB 1W/1M
Data Sheet
